This equipment is primarily used for high-precision double-sided grinding and polishing of sapphire, blue glass, ceramic sheets, crystals, semiconductors, and other hard and brittle materials.
| Item | Specification | Parameter |
|---|---|---|
| Lower Plate | Size (Grinding) | Φ1252mm × Φ708mm × 90mm |
| Rotational Speed | 5-70 rpm | |
| Drive Motor | 15kW AC380V 50Hz | |
| Upper Plate | Size (Polishing) | Φ1260mm × Φ700mm × 90mm |
| Pressure | Maximum 1000kg | |
| Satellite Gear | Quantity | 9 pieces |
| Precision | Plate Flatness | ≤0.02mm |
| End Jump | ≤0.03mm | |
| Processing Range | Max Size | Φ280mm |
| Min Thickness | 0.20mm (≤2" wafer) | |
| Dimensions | L × W × H | 2100mm × 1600mm × 3013mm |
